SVEN SV12120

UPS battery 12V 12Ah

Catalog Electrical Equipment Batteries SVEN SV12120

AN: SV-0222012

SVEN SV12120

UPS battery 12V 12Ah

Short product description:

Lead-acid battery of AGM type
Leak-proof design
Doesn't require maintenance and service
Increased service life

All features

Similar products

SVEN SV645

SVEN SV1250

SVEN SV1270

SVEN SV1272

SVEN SV1290

SVEN SV12170

SVEN SV121000

FEATURES
SPECIFICATIONS
DESCRIPTION
UNBOXING VIDEO
SUPPORT

Lead-acid battery of AGM type
Leak-proof design
Maintenance-free: doesn't require maintenance and can operate in any position
Design of interelectrode separators made of glass fiber increases service life
Does not liberate gas during operation
Valve system protecting the battery against increased pressure
Highly effective lead-calcium electrode grids increasing capacity
Lowered self-discharge current

Battery type	Lead-acid AGM type storage battery
Rated voltage, V	12
Maximum discharge current, A	180
Capacity (20 hours discharge), А • h	12
Maximum charging current, A	3.6
Internal resistance, MOhm	15
Self-discharge (at 25 °C of initial capacity) during the year	up to 36 %
Rated operating temperature, °C	25
Operating temperature range, °C	-20 to +50
Terminal type	F2
Length, mm	151
Width, mm	98
Hight, mm	94
Total hight, mm	100
Weight, kg	3.6
Color	black
Life time	5 years

Other items

SVEN RX-222W

Dual Mode Wireless Mouse (2.4 GHz and Bluetooth)

SVEN PS-670

Multifunctional portable karaoke speaker system with backlight

SVEN MS-150

Speakers with USB/SD player and volume control on the front panel

SVEN HP

Fabric mouse pad with rubber backing

SVEN Pro 800

Line interactive UPS, 480W, 2 sockets

SVEN VR-L1000

Relay automatic voltage regulator, 320 W, 2 sockets

SVEN MP-02 Lake

Fabric mouse pad with rubber backing

SVEN AP-U910MV

Gaming headset with RGB backlight and 7.1 virtual sound

SVEN VR-F600

Relay automatic voltage regulator, 200 W, 2 sockets

SVEN AP-830

On-ear wired headphones

SVEN SPS-585

230V speakers with headphone and microphone jacks

SVEN RX-575SW

Dual Mode Wireless Mouse (2.4 GHz and Bluetooth)

As of today the lead-acid maintenance-free batteries of AGM type are the most widespread type of batteries for the reserve power supply. The main fields of application are UPS; light, alarm and security systems; direct-current power supply; automatic control system.

Batteries of SVEN SV series are notable for the following specifications: low self-discharge current, wide operation temperature range, high coefficient of efficiency and quality of manufacture.
